- Hign-concerned Chemical: None
- RAID Supported: No
- Processor compatibility: Intel Xeon,Intel Others,Intel Xeon E Series
- Usage Scenario: Gaming,Audio & Video,Household,Office,Design,Video Production,Industrial Computer,Workstation,Server,Scientific Computing,3-D Modeling,Video Rendering,MaxCompute,others,HPC
- Back I/O Ports: 1x RJ45
- Onboard LAN: 1x RJ45
- Number of M.2: 1
- Storage Interface Type: SATA 2,SATA 3,M.2 (NVMe)
- Number of PCI: 2
- Number of PCIe x 1: 1
- Number of PCIe x 16: 1
- PCI – E standards: PCI-E 3.0
- Number Of Memory Slots: 4
- Support Memory Type: DDR4
- Memory channel: Double
- Form Factor: CeB
- Package: Yes
- Maximum Ram Capacity: 128 GB
- Form Factor: Micro-ATX
- Chipset Manufacturer: Intel
- Battery Included: No
- With CPU: No
- Chipset: Intel X99
- Application: Desktop
- Socket Type: LGA 2011-3
- Brand Name: QIYIDA
- QIYIDA Model: x99
- Special Features: Cooling Armor
- Origin: Mainland China
Notice：
ALL RAM needs to install in slot (grey slot)priority
The front USB needs to be correctly inserted into the designated USB pin position (yellow pin).
Attention: A 2032 battery needs to be installed to start the computer, otherwise it cannot be started
If inserted in the wrong location, it can cause the computer to not start.
What in the package?
motherboard+cooler adapter+SATA cable
Feature:
100% brand new and high quality!
Support REG ECC server memory/desktop memory Note that server memory and desktop memory. The two types of memory cannot be mixed together.
Support M.2 NVME/NGFF SSD.
High compatibility for a higher experience.
All solid capacitors, fine workmanship, professional stability.
The power socket has an 8-pin, 24-pin power connector.
Motherboard dimension: 215mm*190mm.
Notice for motherboard combine RAM
ALL RAM needs to install in slot#1and slot#4(grey slot)priority
when 1RAM+motherbard (ram needs to install slot#1or #4.)
when 2RAM+motherbard (ram needs to install slot#1and #4.)
when 3RAM+motherbard (ram needs to install slot#1and #4.and#2or#3.)
when 4RAM+motherbard (install all slots)
The black ram slot of motherboard can’t works alone.
Specification:
Main chipset: C612/Q87/H81/B85etc., random delivery. thank you. If you can’t accept it, please don’t buy it. Buying means that you agree to the terms.
Model : QIYIDA
Condition: Full new
CPU socket: LGA 2011-3
CPU supported:for Intel series with LGA 2011-3 socket
(E5 V3,V4 series )
Memory socket: 4* DDR4
Memory Standard ：Support channels DDR4 3200/2666/2400/2133/1866 MHz
Max memory supported: 4*32G DDR4
Memory type supported: non-ecc/reg ecc/ecc(The server ram can’t work with the desktop ram, it has the compability problem.)
Integrated video card: No
Motherboard dimension: 215*190mm
Motherboard weight(including package): 0.9kg or so
Note:
1:The platform needs powerful power. Please make sure your power supply is sufficient to support it(at least 500w power supply) .
2:Please allow 1-3mm differs due to manual measurement.
3:Due to the different display and different light, the picture may not show the actual color of the item. Thanks for your understanding.
4:The battery in motherboard photos will be removed before shipping, as battery is forbidden at CN post and custom.
5:We show photos of motherboard, pictures are for reference only, subject to our available products.
6.For Customs duties problem , pls make sure you can solve the customs clearance problems by yourself, if you can’t solve it, we don’t advise you to buy goods in our store. We are not responsible for customs duties. Thanks for your kindly understanding！
Note：
Due to computer accessories is toomuch,are likely to have some small brand,bad quality or ES/QS version of the CPU, RAM, M. 2 SSD or other accessories may occur incompatible situation with motherboard.You can confirm with our customer service before purchase. if there is no confirmation before purchase then incompatible happen when you receive the motherboard, we would not accept a refund, when you buy this link of single motherboard we default you have read and know the situation.Mind please don’t buy!
X99 Desktop motherboard LGA 2011-3 with M.2 slot Support Four-channel DDR4 Memory SATA3.0 USB3.0
